More Opus Panels in Revit 2010

Ok; you guys set me a challenge. After showing the Opus panel I created in Revit 2010, which I posted earlier this week, you asked when was I going to add thickness! Well, after some head scratching, here you are. :-)

opus panel_v2_0

Here are a few renders....looks far better when it has thickness.

opus panel_v2_1

opus panel_v2_2

5 comments :

James Van said...

Looks great David! How flexible is the component?

David Light said...

Hi James, thanks for the kind comments. To answer your question, at the moment the panel is limited to planar surfaces only. You can change the overall panel size, but as soon as you try to deform the panel, it fails. :-( However, the next challenge it to try to get it to work around a curved surface.

12cadd said...

Hey David, any chance you could get around to doing a vid on the construction of this great panel, would love to see how its done, thanks very much in advance.

12cadd said...

Hey David, any chance you could get around to doing a vid on the construction of this great panel, it would be great to see how its made.

Callum Barr said...

hi david. looks great,i am a student and trying to do a facade like this. but have no idea how to make something like this. is there any chance you can explain how you were able to make this?
thanks
callum
