Thursday, August 28, 2014

Autodesk 3ds team looking for Revit Users interested or using 3ds Max Design for visualizing Projects!


Autodesk M&E 3ds Max Gunslinger summit is a design-focused participatory event in Montreal (Canada) between our users and members of the Autodesk 3ds Max product management, development and design teams. The event is comprised of a series of workshops, design reviews, validation discussions, design charrettes, and more.

3ds Max and 3ds Max Design tools and technology have been used by visualization experts to tell the story of a design in dynamic presentations and won many awards in the entertainment industry.   Clients consistently respond to exploring their project or product in context, within their existing surroundings and bustling with life.  They, and other stakeholders, also find that video helps them understand complex information about the design.   This could be anything from construction logistics, complex function (such as a sliding roof), the impact of design options, or visualization of traffic, weather, stress, airflow and energy.    Cinematic storytelling techniques can convincingly evoke emotions and convey these messages with style.   Unfortunately, in the past, you’d need a large budget to deliver presentations that include these elements.   There are many ways to solve these issues but your feedback is essential.  This is why we’d like to meet with you in person.

We are looking to locate people who would be interested or available in attending.   The Gunslinger is by invitation only as we can only accommodate so many, and other than travel, all shuttles, hotel, and meals are included by Autodesk.   The meeting would be 4 days, Sept 16-19.    It is an opportunity to meet our team and influence tools that could help you improve the way you communicate your designs.

If you are interested in the Gunslinger please let us know by completing a short survey.  We will then be reviewing the submissions for selecting users but if you are unable to attend this specific Gunslinger but are interested in future events please do fill out the survey.

https://autodeskfeedback.az1.qualtrics.com/SE/?SID=SV_cTvMgy21fXPtdk1

Friday, August 08, 2014

Learn what’s new in Revit 2015 subscription advantage

New in Revit 2015 Subscription Advantage

imageBelow you can find a list from the Revit 2015 User help which highlights all the new features & functionality in the forthcoming Revit 2015 Sundial Subs Advantage release. If you want to try it, why not download the Hosted version…more details can be found here

http://www.autodesk.com/campaigns/revit-sundial

Also, keep an eye on the http://insidethefactory.typepad.com/ blog which is back after a long vacation. You will find articles, areas of comments etc on this release.



Architectural Enhancements

  • Solon Integration: Personalize the building performance analysis experience in Revit by defining a dashboard with charts and results that are important to you. The central web-based Solon management environment allows you to create charts and configure dashboards for all of your company Revit users from a central collaboration environment in Green Building Studio.
  • Energy analysis: To better support the analysis of large models, several methods have been implemented to reduce memory usage.
  • Wall joins: To simplify the control of wall joins in a plan view, you can now select multiple intersected wall joins with a single click, and choose to allow or disallow joins on all the selected walls with a single click. If you choose to allow joins, you can then specify a Display option (Clean Join, Don't Clean Join, Use View Setting). See Specify Wall Join Cleanup Options.
  • IFC references and phases: Use existing geometry in a linked IFC model as references for dimensions, alignment, snapping, and hosting of some face-based families in the Revit model. When you link an IFC file, its elements are assigned to a default phase. Before using IFC Import, Link, or Export, go toAutodesk Exchange Apps for Autodesk Revit and download the latest edition of IFC for Autodesk® Revit® to take advantage of up-to-date improvements.
  • Shaft openings: To streamline the creation of a shaft opening, the Base Constraint value now defaults to the level of the current activated plan view. (SeeCut a Shaft Opening.) The instance properties have also been reordered to be consistent with families with similar properties: Base Constraint, Base Offset, Top Constraint, Unconnected Height, and Top Offset.
  • Adaptive point orientation: To improve clarity, the adaptive point instance parameter Orientation is now Orients to, and the selectable orientations have been renamed. No functionality has changed, only the names. See Adaptive Point Orientation.
  • Site design: Performance enhancements result in improved edit and regeneration times for complex toposurfaces, subregions, and building pads.
  • Perspective views: Certain modeling capabilities are now available in perspective views: (See Work in a Perspective View.)
    • Editing tools: Move, Align, Pin, Unpin.
    • Reset Target tool: Restores the position of the camera target to the center of the field of view.
    • Toggle between the perspective and parallel representations of the 3D view.
  • Reference other view: To search the list of available views for reference, enter keywords to locate the desired view. This feature is available when you are creating views for callouts, sections, elevations, and details, and you select the Reference Other View option (or modify a reference view). Also note that the Reference Other View option now displays on the Reference panel of the ribbon instead of the Options Bar. See Reference a Drafting View andSearch.
  • Reveal constraints: To see all dimension constraints and alignment constraints in a view, use the Reveal Constraints mode, available on the View Control Bar. See Reveal Constraints.
  • View updates: Performance enhancements result in faster updates to views that contain multiple instances of families.
  • Revit links: Further enhancements result in improved performance for cases where Revit link instances are loaded but not visible in the view (such as when they are outside the crop region).
  • PDF Export enhancements:
    • Share your designs as electronic PDF files with automatically linked views and sheets. Each view tag in the PDF file is a hyperlink. Click a hyperlink to jump to that view or sheet in the PDF file. See About Printing to PDF.
    • Avoid lengthy or unintended print jobs. If you choose to print multiple views and sheets to individual PDF files, you cannot cancel the print job once it starts. A new message warns you of this issue and allows you to cancel the print job before it starts. Instead, consider printing the views and sheets to a single PDF file. See Troubleshooting: Printing Views and Sheets.
  • Schedules: To easily add a data row to a schedule, use the Insert Data Row tool, which is available directly on the Rows panel instead of within the Insert drop-down. The new position of this tool makes it easier to add a data row to a room schedule, area schedule, key schedule, space schedule, or sheet list. See About Modifying Schedules.
  • Select host for tags: To specify the host element for a tag, select the tag and use the Select Host tool. See Select the Host for a Tag.
  • Annotate stair treads and risers: To streamline the process of adding number annotations to treads or risers in a component stair run, specify default properties before placing the annotation. These default property values persist for tread/riser annotations added to the model. See Number Stair Treads and Risers.
  • Thin lines: To improve consistency between Revit sessions, when you use the Thin Lines tool, the setting is stored in the Revit.ini file. When you launch Revit, the stored Thin Lines setting is used as the default. See Graphics Settings in Revit.ini.
  • Export Models with Lines that Coincide: When exporting a Revit model to a CAD format, you can decide whether to maintain model lines that coincide with other lines in the same space. See About Exporting Models with Lines that Coincide.

Structural Enhancements

MEP Enhancements

  • Sequence for power circuits: To specify the sequence in which power circuits are created, use the Electrical Settings dialog. See Electrical Settings.
  • Most recently used panel circuiting: When you create a circuit, Autodesk® Revit® automatically connects to the most recently used panel for the current session. In addition, you can now search the Panel drop-down list. See Select a Panel or Transformer for the Power Circuit.
  • Move circuits: To move a circuit directly to a target slot without disrupting other circuits, use the Move To tool. See Move circuits on panel schedules.
  • ASHRAE table information: To identify the table that is applicable for the current condition, the ASHRAE Table Settings dialog displays the graphical representations associated with the duct fitting tables. This enhancement is helpful when you specify Coefficient from ASHRAE Table as the loss method for duct fittings. See Specify a Pressure Loss Method for Fittings and Accessories for Duct and Pipe.

Multi-Disciplinary Enhancements

  • Search: To quickly find the content you need, use the new search feature in the Type Selector or in drop-down lists. Click the Type Selector or a value field in the Properties palette or a dialog table, and enter keywords to search for. See Search.
  • File upgrades: To help you understand the consequences of file upgrades, new dialogs indicate the release of a file and the release to which it will be upgraded. In many cases, you have the opportunity to cancel the upgrade before it completes. See About Opening Models that Require an Upgrade.
  • Edit/load a family: To close the family automatically after it is loaded into a project, use the Load into Project and Close tool in the Family Editor. See Load the Current Family into a Project.
  • Properties palette: Keep your context in the Properties palette when you scroll, select a property, and then click outside the palette. This behavior can be helpful, for example, if you are selecting different family instances in the model to compare their properties.
  • Pin/Unpin icons: To determine whether an element has a relationship with a host system, select the element to see its Pin/Unpin tool icon. A different set of pin/unpin images () is used in the drawing area to indicate a relationship with a host, such as a curtain wall panel or a beam in a beam system. The behavior of the pin has not changed (clicking it still allows you to override the properties for the element), but the subtle difference (small link in the image) adds a visual indicator that this pin is different than the standard pin that locks an element in position. The Pin/Unpin tool icons on the ribbon have not changed. See Unpin Elements.
  • Import/link position: To streamline the process of inserting a Revit model or a CAD file, the default positioning is now Auto - Origin to Origin. If you change the default, the option you select for Positioning becomes the default for the current Revit session. The software remembers one default option forRevit models and another default option for CAD files. See Import and Link Options.
  • Revit link in a closed workset: To understand why a Revit link is not visible in model views, check its status in the Manage Links dialog. The status In Closed Workset now displays for a Revit link that is in a closed workset. See Manage Links Dialog.

Configuration Changes

In the Revit.ini file, the following settings are new or changed in this release:

  • Colors section: The new BackgroundColor setting replaces the InvertBackground setting in the Graphics section.
  • Graphics section: The ThinLinesEnabled setting is now supported. The InvertBackground setting has been deprecated and is no longer supported.

Saturday, May 31, 2014

BIM 360 info & Autodesk 360 Viewer

I’m excited by where BIM 360 is going. Its worth reviewing this article at Jeremy Tammik’s The Building Coder blog. It’s a useful insight into the direction of Glue & Field with regards to API access…..& this is only the beginning. Watch out for some interesting developments going forward….

http://thebuildingcoder.typepad.com/blog/2014/05/updated-sdk-devtv-bim-360-news-and-viewer.html

One other thing, be sure to read up about the new Autodesk 360 viewer at Ken Walmsley’s Through the Interface blog. I’ve had a good play with this & its very impressive.

http://through-the-interface.typepad.com/through_the_interface/2014/05/a-sneak-peek-at-the-new-autodesk-360-viewer.html

Use the link below….. to open a model to play with….note this only works with Google Chrome, Firefox or other WebGL 3d graphic enabled browsers.


https://s3.amazonaws.com/FastViewer/index.html?file=Revit_Kitchen/0.svf


File Upgrader – Revit 2015

From experience its about this time when Revit users / BIM managers start to look at deploying the latest version of Revit; a service pack has typically been issued & things are slowly settling down. One thing you are going to want to do is upgrade all your content to the latest version. People use various tools such as batch files, journals etc. But can I suggest you take a look at Revit File Upgrader from Harry Matterson @ Boost Your BIM? Harry released a 2014 version which you will find on the Autodesk App Store.


However, he has also released a awesome 2015 version, it does exactly what it says on the tin! Harry has given it away for free; so be sure drop by his website & thank him. You can download it from here.

Monday, April 07, 2014

Revit 2015 – Trim / Extend Multiple Elements

This is a reasonably simply improvement. If you are laying out a lot of walls, quickly being able to trim & extend so they cleanup is an essential requirement for any designer, especially if they have come from a CAD background. Over a number of releases we have seen usability enhancements which have migrated their way to the Revit platform, based on tried & tested CAD methodologies. For instance if you have ever used AutoCAD you might have used the fence command. In Revit 2015 you can now use a selection box to select multiple elements to trim or extend to a boundary defined by another element. Note; you are still able to select individual elements to trim or extend. The video clip below shows the functionality performed on walls, but it will happily work on other elements such as structural beams. A simply, but time saving, valuable enhancement.

Sunday, April 06, 2014

Revit 2015 – sketchy lines

Sometimes when using BIM for presentation purposes, especially during the design development stages, the digital outputs can look a little too polished. In the past an architect might of used hand drawn sketches & diagrams to convey the design. New for Revit 2015 is the Sketchy Lines feature which emulates a hand drawn visual style. This feature is available to be applied to any graphic display style including 3d views, perspective views, elevations, sections & plan views.

You can adjust settings for Jitter and Extension to create unique interpretations of any visual style as shown. The Jitter slider allows to vary the weighting & clarity of the line as if you had drawn it with a pen or pencil, where as the Extension slider allows you to how far lines overlap at intersections. Check out Tim Waldocks detailed overview for more examples of how this feature can be used.

A 3d view with the Jitter set to 7 & no Extension:-


A 3d view with no Jitter & the Extension set to 10:-


The combination of the Jitter set to 7 & Extension set to 10:-
